LR-FL2100 Liquid Fluorosilicone Rubber for electronic potting - Silfluo
Fluorosilicones

RTV Fluorosilicone Liquid Rubber – LR-FL2100

Product Code: Silfluo LR-FL2100

Chemical Name Room Temperature Vulcanizing (RTV) Liquid Fluorosilicone Rubber
Product Form Liquid
Download TDS Request Sample

Product Description

LR-FL2100 is a liquid fluorosilicone rubber (FVMQ) characterized by its outstanding resistance to extreme temperatures, fuels, and oils, as well as excellent electrical insulation properties. It is designed to cure effectively at room temperature.

Typical Technical Properties:

Project Test Method FL3400
A component color Visual Inspection Pale yellow
B component color
Component A Viscosity/Pa.s
(Shear rate 10s-1)		 Rotational Viscometer Method 350
Component B Viscosity/Pa.s
(shear rate 10 s-1)		 300
25℃×48h
Density /g/cm3 ASTM D792 1.42
Hardness /Shore A ASTM D2240 35
Tensile strength /MPa ASTM D412 8.1
Elongation at break /% ASTM D412 320
Tear strength /kN/m ASTM D624-B 14.5
Resilience /% ASTM D1054 36
Compression set /%
(177 °C× 22h)		 ASTM D395 21
Fuel C/%（25℃×72h） ASTM D471 24.0



Applications

LR-FL2100 is recommended for:

  • Two-part RTV sealing and gasketing (FIPG) for assemblies requiring fuel/oil resistance;
  • Potting / encapsulation of electrical and electronic components for elastic protection and electrical insulation in fuel/oil exposure environments;
  • Sealing of connectors, cable entries, and sensor housings under temperature cycling and fluid exposure;
  • Elastic gap filling and vibration damping in harsh environments across a wide temperature range;

How to use:

LR-FL2100 liquid fluorosilicone rubber is supplied as a two-component system. Mix components A and B thoroughly in a 1:1 weight ratio, followed by vacuum deairing. The mixture will achieve full cure after 48 hours at room temperature (25°C±5°C).

Application Scenarios

Aerospace & Defense Automotive & New Energy (EV) Oil, Gas & Marine Power Generation & Nuclear

Packaging & Handling

Plastic drum packaging, A/B components each 20kg separate packaging.

Keep in cool, dry place. Avoid contact with compounds containing nitrogen, sulfur, phosphorus, and heavy metals to prevent product deterioration, shelf life is 12 months from the date of production. It is shipped as non-hazardous substance. Avoid contact with compounds containing nitrogen (N), sulfur (S), phosphorus (P), and heavy metals, as these substances may inhibit the vulcanization process or lead to incomplete curing.
